Menu Description
188
Network setting
initialization
The following network settings are initialized.
Settings configured from the projector menu
• Network settings lock (P183)
• Network password setting (P183)
• Register network password (P183)
• Network (wired/wireless) (P184)
• Detailed settings (wired) (P185)
- Detailed IPv4 address settings (P185)
- DHCP (wired LAN (IPv4)) (P185)
- TCP/IP settings (P186)
- IP address (wired LAN (IPv4)) (P185)
- Subnet mask (wired LAN (IPv4)) (P185)
- Gateway address (wired LAN (IPv4)) (P185)
- IPv6 (P186)
- Detailed IPv6 address settings (P187)
- Auto settings (P187)
- Manual settings (P187)
- IP address (wired LAN (IPv6)) (P187)
- Prefix length (P187)
- Gateway address (wired LAN (IPv6)) (P187)
• PC-free multi projection
Destination projector setting
[1]IP address – [9]IP address
• PJLink (P194)
• AMX Device Discovery settings (P195)
• Crestron RoomView settings (P195)
Settings configured from the web screen
• [Password] (P198)
• [Wired] (P204)
-
IPv4
- DHCP (P205)
- IP address (P205)
- Subnet mask (P205)
- Default gateway (P205)
- IPv6
- IPv6 (P205)
- Autoconfiguration (P205)
- IP address (P205)
- Prefix length (P205)
- Default gateway (P205)
• [NMPJ Password] (P208)
• [Mail] (P209)
• [SNMP] (P211)
• [Projector info.] (P212)
• [PJLink] (P213)
• [IPsec] (P214)
